Components > Graphics Cards

XFX RX7900 XT Speedster MERC310, 20GB DDR6, HDMI, 3 DP, 2535MHz Clock, Z Support Bar

+ click images to enlarge

Stock Code

RADRX79XT20XFMERC310

Manufacturer

XFX

Manufacturer Code

RX-79TMERCU9

EAN Number

840191500671

Printable Version

11 Available

You must be logged in to view pricing and place orders

Chipset Manufacturer

AMD

Interface

PCI Express 4.0

Graphics Chipset

AMD RX 7900 XT

Memory Size

20GB

Memory Type

DDR6

Memory Interface

320-bit

Core Clock

Base Clock: 1775 MHz
Game Clock: Up to 2175 MHz
Boost Clock: Up to 2535 MHz

Memory Clock

20 Gbps

CUDA Cores / Stream Processors

5376 Stream Processors

Outputs

1 x HDMI 2.1
1 x DisplayPort 1.4
2 x DisplayPort 2.1

DirectX Support

DirectX 12 Ultimate

Max Display Support

Cooling

Triple Fan Design
Double Ball Bearing Fans - Quieter & Longer Lifespan
XFX Ghost Thermal design
Vapor Chamber design

PSU Requirements

750W or greater recommended

Connectors Required

2 x 8-pin PCIe power

Additional Features

See Overview

Dimensions

34.4 x 12.8 x 5.5 cm

Slot Size

2.7 Slot

Accessories

Warranty card - QR Code Insert
1 x Z Support Bar

Package Type

Retail

Package Weight

2.4200 kg

Warranty

3 Years

Full Box Quantity

Manufacturer Link

Click here for more details from the manufacturer

XFX SPEEDSTER MERC 310 AMD Radeon™ RX 7900 XT

Game Clock: Up to 2175 MHz
Boost Clock: Up to 2535 MHz
GDDR6 Memory Size: 20 GB
Memory Clock Speed: 20 Gbps

Performance to Rule Your Game

Built on the groundbreaking AMD RDNA™ 3 architecture with chiplet technology, AMD Radeon™ RX 7900 XT graphics deliver next-generation performance, visuals, and efficiency at 4K and beyond.

Speedster Series

The Speedster series exemplifies a modern aerodynamic style though clean and elegant design. It is a thoughtful design with the sole purpose of maximizing airflow to improve cooling and performance.

Airflow and Aesthetics

With each iteration of the XFX Merc series, we have simplified the design while improving performance.

XFX Ghost Thermal

Our new design features a stright through airflow venting to significatly improves cooling and compliments open design of the Ghost Thermal floating shroud design along with numerous other cooling features.

Vapor Chamber

The XFX 7900 Series brings back the vapor chamber design, a more efficient method for heat dissipation than traditional cold plates alone. The vapor chamber can quickly quickly and efficiently transfer heat from the GPU and VRAM to the heat pipes, and then into the heatsink assembly.

XFX Dual BIOS Ready

We know enthusiast like options, so for our MERC Line of 7900 Series graphics cards we are offering dual BIOS . Giving a backup BIOS in the case of a failed BIOS update or flash.

Double Ball Bearing Fans - Quieter & Longer Lifespan

The MERC 310 GPUs utilize double ball bearing structure fans that provide better endurance and efficiency over other designs. Reducing friction and heat these, fans operate quieter and have increased lifespan.

Extreme Stability and Overclocking

A 10+3+1 phase power design implements a large V-Core allowing it to provide you with stable gameplay, and giving better power distribution across the VRMs.. This allows the GPU to operate cooler at baseline but also have tremendous room to overclock thanks to XFX's increased power delivery BIOS.

Breakthrough Performance

Breakthrough new levels of performance with 20GB of GDDR6 memory and blazing fast clock speeds to deliver an incredible experience at 4K and beyond. Radeon™ RX 7900 Series graphics feature advanced AMD RDNA™ 3 compute units, with 2nd generation raytracing accelerators and new AI accelerators to deliver incredible performance while maximizing graphical fidelity.

World’s First Chipset Designed Gaming GPUS

Featuring ultra-fast 2nd generation AMD Infinity Cache™ technology connected through an ultra-high bandwidth chiplet interconnect.

Breathtaking Visuals

A pixel perfect experience starts with Radeon™ RX 7900 Series graphics cards. Immerse yourself in your favorite visual vistas with stunning image clarity and up to 68 billion colors at up to 8K 165Hz. The Radeon™ RX 7900 Series delivers a jaw-dropping visual experience you need to see to believe.

AMD Radiance Display™ Engine

The AMD Radiance Display™ Engine features 12-bit HDR and full coverage of the REC2020 color space for incredible color accuracy. With support for DisplayPort™ 2.1, experience breathtaking visuals with up to 68 Billion colors at up to 8K 165Hz. • DisplayPort™ 2.1 • 12-Bit HDR up to 68 billion Colors

Advanced Gaming and Creation Platform

Build the ultimate desktop when combining the latest Ryzen™ processors and Radeon™ graphics for breakthrough performance and remarkable power efficiency. Take your experience to the next level with AMD smart technologies4 and AMD Software: Adrenalin Edition™ applications. Radeon™ RX 7900 Series graphics are the ultimate plug-and-play solution, integrating seamlessly with existing ultra-enthusiast power supplies and cases with optimized system power, thermals, and noise levels.

AMD FidelityFX ™

AMD FidelityFX™ Super Resolution technology1 takes upscaling technology to the next level. Providing incredible image quality while boosting framerates in supported games. AMD Radeon™ Super Resolution (RSR)2 leverages FSR technology on the driver level, giving you upscaled performance benefits across thousands of games.

AMD Infinity Cache

A revolutionary new memory level in AMD RDNA™ 3 architecture. 80 MB of AMD Infinity Cache enables high bandwidth performance 2900 GB/s Effective Memory Bandwidth

AMD Smart Access Memory

Get more performance in select titles through new levels of communication between AMD Ryzen™ desktop processors and AMD Radeon™ graphics cards over PCIe® 4.0

High Performance 4k Gaming

With up to 84 enhanced compute units delivering powerhouse performance, even 8K gaming is now possible at smooth framerates thanks to FSR.

GDDR6 Memory for Advanced Gaming

Equipped with 20GB of advanced GDDR6 memory with a 320-bit interface , enabling 4k performance in today’s most demanding games.

PCI® Express 4.0 Support

The AMD Radeon™ RX 7000 Series graphics cards feature PCIe® 4.0, with a throughput of 16 GT/s which enables two times the bandwidth compared to PCIe® 3.0.

500 Million Gamers Play on AMD Radeon

AMD Power most of todays newest consoles but also more Gaming PCs and Consoles are powered by AMD*. It's obvious what is the real choice when it comes to high performance graphics at a great value.

AMD Radeon™ is Windows 11 Ready

Windows® 11 is created for the ultimate PC gaming, featuring superior graphics, amazing speed, and an incredible selection of games. Windows 11 includes gaming features like DirectX® 12

XFX 3 Year Warranty

Even though we trust that our high quality products will continue working at peak performance well beyond the use of it, we want to put our word behind that promise. That is why we offer our 3 Year Warranty with this series of graphics cards. This means that your product is protected by a 3 year limited hardware warranty on manufacturing defects of anything on the card.
