Components > Graphics Cards

Asrock Intel ARC A750 Challenger D 8GB OC, 8GB DDR6, PCIe4, 2 HDMI, 2 DP, 2200MHz Clock, 0dB Cooling, Overclocked

+ click images to enlarge

Stock Code

INARA7508ASRCLDOC

Manufacturer

ASROCK

Manufacturer Code

90-GA3HZZ-00UANF

EAN Number

4710483940316

Printable Version

20 Available

You must be logged in to view pricing and place orders

Chipset Manufacturer

Intel

Interface

PCI Express 4.0

Graphics Chipset

Intel Arc A750

Memory Size

8GB

Memory Type

DDR6

Memory Interface

256-bit

Core Clock

2200 MHz

Memory Clock

16 Gbps

Intel XMX Engines

448

Outputs

1 x HDMI 2.1
1 x HDMI 2.0b
2 x DisplayPort 2.0

HDCP Support

Yes

Resolution

Digital Max Resolution: 7680 x 4320

DirectX Support

DirectX 12 Ultimate

Max Display Support

Cooling

Dual Fan Design
Stylish Metal Backplate
Striped Axial Fan
Ultra-fit Heatpipe
0dB Silent Cooling

PSU Requirements

650W or greater recommended

Connectors Required

2 x 8-pin power connectors

Software

Arc Control software

Additional Features

See Overview

Dimensions

271 x 132 x 48 mm

Slot Size

2.4 Slot

Accessories

1 x Quick Installation Guide

Package Type

Retail

Package Weight

1.3000 kg

Warranty

2 Year Replacement Warranty

Full Box Quantity

Manufacturer Link

Click here for more details from the manufacturer

Intel Arc A750 Challenger D 8GB OC

GPU Clock: 2200 MHz
Memory Clock: 16 Gbps
Intel® Arc™ A750 Graphics
8GB 256-bit GDDR6
Intel® Xe HPG Microarchitecture
Intel® Xe Super Sampling (XeSS)
DirectX® 12 Ultimate
2 x 8-pin Power Connectors
2 x DisplayPort™ 2.0 / 1 x HDMI™ 2.1 / 1 x HDMI 2.0b
Dual Fan Design
Stylish Metal Backplate
Striped Axial Fan
Ultra-fit Heatpipe
0dB Silent Cooling
Super Alloy Graphics Card

OC Edition

Great Performance.

Delivers great performance which is more higher than reference cards based on the solid hardware design.

Dual Fan Design

Two fans that provide strong cooling performance and make your gaming rig stay cool. It’s optimized for delivering excellent gaming experience with stylish and streamlined design.

Stylish Metal Backplate

Solid, Fancy, Cool.

Designed to avoid PCB bending. The fancy outlook makes the graphic card more legendary in visual. It also helps to enhance cooling with the premium thermal pads equipped backside.

Striped Axial Fan

Designed For Enhanced Airflow.

ASRock’s custom Striped Axial Fan delivers enhanced airflow to optimize cooling from not only the stripe structure on each fan blade but also the polishing surface on the bottom side.

0dB Silent Cooling

Spin For Cooling, Stop For Silence.

The fan spins when the temperature goes high for the optimal cooling, and stops when the temperature goes low for the complete silence.

Ultra-fit Heatpipe

Consolidated to Maximize the Contact.

The heatpipes are consolidated to maximize the contact among each others and also the GPU baseplate for the optimized heat dissipation.

Nano Thermal Paste

Perfect Thermal Teamwork.

Eliminate the gaps in the contact area to maximize heat transfer and thermal efficiency.

Premium Thermal Pad

Better Heat Transfer.

The premium thermal pad helps to transfer the heat of the components to the heatsink, improving heat dissipation.

Precise Screw Torque

Optimized Mounting Pressure.

ASRock adopts precise screw torque when assembling its graphics cards to optimize the cooler mounting pressure to improve thermal efficiency while avoiding damage to GPU die.

SPS (Smart Power Stage)

Dr.MOS design features the latest SPS (Smart Power Stage) technology. It’s optimized for monitoring current and temperature of each phase, thus delivering smoother and neater power to the GPU with enhanced performance and OC capability.

Premium 100A Power Choke

Compared to traditional chokes, ASRock’s premium 100A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the graphics card.

Matte Black PCB

A new mysterious matte black and copper color scheme to match the prestigious components on ASRock's high-end graphics card.

High Density Glass Fabric PCB

High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the graphics card against electrical shorts caused by humidity.

8K Resolution Support

Not only can it handles 4K graphics but also supports the next generation 8K video output for the ultimate visual experience.

PCI® Express 4.0 Support

This graphics card features PCI® Express 4.0 support, with a throughput of 16 GT/s and enables two times the bandwidth compared to PCI® Express 3.0. Get ready for the next generation of PC gaming.

Supercharge your gaming.

Dive into immersive, high-performance gaming with AI-enhanced XeSS upscaling and full support for DirectX* 12 Ultimate.

Experience immersive high-performance gaming.

Intel® Arc™ Control gives gamers options and controls to refine their gaming experience in an intuitive and modern layout. Get seamless driver updates, optimize your favorite games, stream from your home without interruption and more.

Xe Super Sampling (XeSS)

Take your gaming experience to the next level with AI-enhanced upscaling technology, enabling more performance with high image fidelity.

DirectX 12 Ultimate Support

Fully compatible with the latest breakthroughs in graphics technologies, including ray tracing, variable rate shading, mesh shading and sampler feedback - the fundamentals for next-gen gaming.

Unleash your creativity.

Experience cutting-edge AI-accelerated content creation.

With industry-first AV1 hardware encode and the advanced Intel® Xe Media Engine, the most comprehensive media capabilities1 are at your fingertips.

VGA Unleash your creativity A7

Take center stage.

Broadcast seamlessly with advanced streaming technologies enabled by Intel® Arc™ Control software.

Elevate your gaming experience.

Refine your gaming experience with Intel® Arc™ Control in an intuitive and modern layout. Get seamless driver updates and optimize many of your favorite games.

Maximize your Intel® platform.

Enhance your creation, gaming and streaming experiences with Intel® Deep Link Technology features by pairing Intel® Core™ processors with Intel® Arc™ graphics.
