Fractal Design Prisma AL-14/PWM 14cm ARGB Case Fans (3 Pack), 7 Blades, Long Life Sleeve Bearing, 500-1700 RPM, Black

+ click images to enlarge

Stock Code

CF140-FRPRAL14PWM-3PK

Manufacturer

Manufacturer Code

FD-FAN-PRI-AL14-PWM-3P

EAN Number

7340172701651

Printable Version

17 Available

You must be logged in to view pricing and place orders

Type

14cm Case Fan

Fan Connector(s)

4-pin

Fan Controller

PWM

Installation

Screws

Colour

Black

LED Lighting

6 individually addressable hub-mounted RGB LEDs
Chainable RGB cables
Connector: 3-pin 5V addressable RGB
Adjust R1 RGB controller (sold separately) enables physical control of colours and effects

Weight

200 g

Fan Dimensions

140 x 140 x 25 mm

Rotation Speed

500 - 1700 RPM

Fan Bearing

Long Life Sleeve

Air Flow

103.85 CFM

Noise level

34.1 dB(A)
Low PWM: 15.1 dB(A)

Power

Fan input power: 2.16 W
Fan max input current: 0.18 A
Fan input voltage: 12 V
Fan starting voltage: 7 V
LED input power: 1.50 W
LED max input current: 0.30 A
LED input voltage: 5 V

Additional Features

See Overview

MTBF

100,000 hours

Package Contents

3 x Prisma AL-14 PWM 140 mm fan
12 x fan screws (3-pack)

Package Type

Retail

Package Weight

0.6950 kg

Warranty

3 Years

Full Box Quantity

1

Manufacturer Link

Click here for more details from the manufacturer
