Networking > Routers / Mesh Systems

TP-LINK (DR3650v) Omada AX3000 Wi-Fi 6 Gigabit Desktop DSL Gateway, Dual Band, VDSL2 35b, USB 3.0, VoIP Support, Centralized Management, Mesh Technology

+ click images to enlarge
Stock Code
ROU-AX3000TPOMAVADSL-GB
Manufacturer
Manufacturer Code
DR3650V
EAN Number
8885020626766
1 Available
You must be logged in to view pricing and place orders
Type
VDSL2/ADSL2 Router
Connectivity
Wireless
Wi-Fi Rating
AX3000
Max Single Band Wi-Fi Rate
2402 Mbps
Max Wired Transfer Rate
10/100/1000 Mbps
Bands
Dual Band
Signal Rate
5 GHz: 2402 Mbps
2.4 GHz: 574 Mbps
Interface(s)
3 x RJ11 Ports (2 x FXS, 1 x DSL)
5 x RJ45 Gigabit Ports (1 x WAN/LAN, 4 × LAN)
2 x USB 3.0
Frequency
2.4 GHz & 5 GHz
Button(s)
Reset Button
Power Supply
12VDC / 3.3A Power Adapter
Max Power Consumption: EU: 16.8W (with USB 3.0 connected), 11.8W (without USB 3.0 connected)
Antenna(s)
2.4 GHz: 2x 3 dBi dual-band detachable antennas
5 GHz: 3x 4.5 dBi dual-band detachable antennas
Dimensions
(WxDxH) 226 x 131 x 35 mm) (Antenna dimensions are not
included)
Wireless Functions
Seamless Roaming
Mesh (with EAP that supports Mesh)
OFDMA
Beamforming
MU-MIMO
Security
WiFi Encryption:
WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise

Filtering:
Web Group Filtering
URL Filtering
Web Security

ARP Inspection:
Sending GARP Packets
ARP Scanning
IP-MAC Binding

Attack Defense:
TCP/UDP/ICMP Flood Defense
Block TCP Scan (Stealth FIN/Xmas/Null)
Block Ping from WAN

Access Control:
Source/Destination IP Based Access Control
DHCP
DHCP Server
DHCPv6 PD Server (only in Standalone Mode)
DHCP Options Customization
DHCP Address Reservation
Multi-IP Interfaces
Multi-Net DHCP
Port/NAT Forwarding
66 Byte Packet forwarding rate:
1,453,489 pps / 1,453,488 pps

1,518 Byte Packet forwarding rate:
81,274 pps / 91,275 pps
VPN Support
SSL VPN:
50 Tunnels

IPsec VPN:
100 IPSec VPN Tunnels
LAN-to-LAN, Client-to-LAN
Main, Aggressive Negotiation Mode
DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
IPsec Failover
IKE v1/v2
MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm
NAT Traversal (NAT-T)
Dead Peer Detection (DPD)
Perfect Forward Secrecy (PFS)


PPTP VPN:
PPTP VPN Server
PPTP VPN Client (10)
50 Tunnels
PPTP with MPPE Encryption

L2TP VPN:
L2TP VPN Server
L2TP VPN Client (10)
50 Tunnels
L2TP over IPSec

OpenVPN:
OpenVPN Server
OpenVPN Client (5)
55 OpenVPN Tunnels
"Certificate + Account" Mode
Full Mode

WireGuard VPN:
20 Tunnels
Management
Omada App
Centralized Management
Cloud Access
Zero-Touch Provisioning

Maintenance:
Web Management Interface
Remote Management
Export & Import Configuration
SNMP v1/v2c/v3
Diagnostics (Ping & Traceroute)
NTP Synchronize
Port Mirroring
CLI (only in Standalone Mode)
Syslog Support
TR-069 (data models of TR-098 and TR181 are supported)


Management Features:
Automatic Device Discovery
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
Captive Portal Configuration
Dynamic DNS
Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)
USB Application
Supports 4G/3G dongles
Additional Features
Flash: 256 MB NAND
DRAM: 512 MB DDR4
Desktop/Wall-mounting
Guest Network
Environment
Operating Temperature: 0C°~40°C (32°F ~104°F)
Storage Temperature: -40°C to 70°C (-40 °F to 158 °F)
Operating Humidity: 10% to 90% non-condensing
Storage Humidity: 5% to 90% non-condensing
Package Contents
DR3650v
Power Adapter
Ethernet Cable
Phone Cable
Quick Installation Guide
Package Type
Retail
Package Weight
1.7900 kg
Warranty
Limited Lifetime
Full Box Quantity
6
